Bob Light XL

Finish

Painted aluminum in white RAL 9010, greybrown RAL 7006, black RAL 9005, orange RAL 3022, grey RAL 7030. Diffuser in matt acrylic. Other colours on request.

LED info

System power: 14W. Luminaire Luminous Flux: 955LM. CCT 3000K. SDCM 3. CRI >90. L80/72.000H

Installation

Suspended from ceiling 2,5 m cable. Including cable-cup.

Connection

DCL plug or terminalblock 3x4 mm2. When DALI 5x4mm2.

Design

Thomas Bernstrand & Stefan Borselius 2022.

product sheet



			Product specification
			It started with a modular sofa system getting an integrated light fixture. And the latter had the same pleasantly rounded shapes of the former.After that, more and more members joined the Bob family, including a floor light, a solo pendant and a bow that waves through the space. And now, a really large pendant, Bob XL: 400 mm in diameter.


				POWER/LUMINAIRE FLUX
				MODEL
				KELVIN
				CRI
				COLOUR
				ART.



					14W/955LM
					On/Off
					3000K
					>80
					White
					19100301-30


					14W/955LM
					DALI
					3000K
					>80
					White
					19100301D30


					14W/955LM
					On/Off
					3000K
					>80
					Black
					19100306-30


					14W/955LM
					DALI
					3000K
					>80
					Black
					19100306D30


					14W/955LM
					On/Off
					3000K
					>80
					Grey
					19100311-30


					14W/955LM
					DALI
					3000K
					>80
					Grey
					19100311D30


					14W/955LM
					On/Off
					3000K
					>80
					Orange
					19100341-30


					14W/955LM
					DALI
					3000K
					>80
					Orange
					19100341D30


					14W/955LM
					On/Off
					3000K
					>80
					Greybrown
					19100366-30


					14W/955LM
					DALI
					3000K
					>80
					Greybrown
					19100366D30


					D = Dimmable DALI, SwitchDim










Product specification It started with a modular sofa system getting an integrated light fixture. And the latter had the same pleasantly rounded shapes of the former.After that, more and more members joined the Bob family, including a floor light, a solo pendant and a bow that waves through the space. And now, a really large pendant, Bob XL: 400 mm in diameter.
POWER/LUMINAIRE FLUX	MODEL	KELVIN	CRI	COLOUR	ART.
14W/955LM	On/Off	3000K	>80	White	19100301-30
14W/955LM	DALI	3000K	>80	White	19100301D30
14W/955LM	On/Off	3000K	>80	Black	19100306-30
14W/955LM	DALI	3000K	>80	Black	19100306D30
14W/955LM	On/Off	3000K	>80	Grey	19100311-30
14W/955LM	DALI	3000K	>80	Grey	19100311D30
14W/955LM	On/Off	3000K	>80	Orange	19100341-30
14W/955LM	DALI	3000K	>80	Orange	19100341D30
14W/955LM	On/Off	3000K	>80	Greybrown	19100366-30
14W/955LM	DALI	3000K	>80	Greybrown	19100366D30
D = Dimmable DALI, SwitchDim

Bob XL - New 2022
