Curve Through table

Finish

Shades and stands in painted metal. Shades in glass are avalible in green or opal white. Diffuser in matt acrylic.

LED info

System power 8W. Luminaire Luminous Flux 170LM - 765LM (see product specification). CCT 3000K. SDCM 3. CRI >90. L70 B10 50.000h.

Installation

Mounted fixed through table-top. Recommended cut-out Ø20 mm - Ø50 mm.

Connection

2,5 m cable with plug. Can be dimmed with external trailing edge dimmer. Intergrated switch on mounting plate on request. Separate outlet matching the fixture on request.

Classification

IP 20.

Design

Front Design 2019.

Standard colours

Other colours on request.



Standard glass shades




Product specification Designed for the newly renovated Art Library at Nationalmuseum, Curve borrows its personality from the classical library lamp. In this transformed interpretation, the suite of pendants, floor and table lamps become calming, languid figures. With metal shades in pigeon-blue, ivory, white or green.
POWER D/mm H/mm Model Color base Shade ART.
8W/170LM 150 432 S Green Green glass 16008112-30
8W/332LM 200 455 S Green Green glass 16008312-30
8W/415LM 300 504 S Green Green glass 16008512-30
8W/170LM 150 568 L Green Green glass 16010112-30
8W/332LM 200 590 L Green Green glass 16010312-30
8W/415LM 300 640 L Green Green glass 16010512-30
8W/465LM 150 432 S White White glass 16008121-30
8W/606LM 200 455 S White White glass 16008321-30
8W/765LM 300 504 S White White glass 16008521-30
8W/465LM 150 568 L White White glass 16010121-30
8W/606LM 200 590 L White White glass 16010321-30
8W/765LM 300 640 L White White glass 16010521-30
8W/138LM 150 432 S White White metal 16009101-30
8W/337LM 200 455 S White White metal 16009301-30
8W/476LM 300 504 S White White metal 16009501-30
8W/138LM 150 568 L White White metal 16011101-30
8W/337LM 200 590 L White White metal 16011301-30
8W/476LM 300 640 L White White metal 16011501-30
8W/138LM 150 432 S Green Green metal 16009112-30
8W/337LM 200 455 S Green Green metal 16009312-30
8W/476LM 300 504 S Green Green metal 16009512-30
8W/138LM 150 568 L Green Green metal 16011112-30
8W/337LM 200 590 L Green Green metal 16011312-30
8W/476LM 300 640 L Green Green metal 16011512-30
8W/138LM 150 432 S Pigeon blue Pigeon blue 16009108-30
8W/337LM 200 455 S Pigeon blue Pigeon blue 16009308-30
8W/476LM 300 504 S Pigeon blue Pigeon blue 16009508-30
8W/138LM 150 568 L Pigeon blue Pigeon blue 16011108-30
8W/337LM 200 590 L Pigeon blue Pigeon blue 16011308-30
8W/476LM 300 640 L Pigeon blue Pigeon blue 16011508-30
8W/138LM 150 432 S Ivory Ivory 16009146-30
8W/337LM 200 455 S Ivory Ivory 16009346-30
8W/476LM 300 504 S Ivory Ivory 16009546-30
8W/138LM 150 568 L Ivory Ivory 16011146-30
8W/337LM 200 590 L Ivory Ivory 16011346-30
8W/476LM 300 604 L Ivory Ivory 16011546-30
