Curve Crown

Finish

Arms and shades in painted metal. Diffuser in opal acrylic. Textile cable.

LED info

Information below is per light source. System power 10 W. Luminaire Luminous Flux 710LM - 783LM (see product specification). CCT 3000K. SDCM 3. CRI>90. L70 50000H.

Installation

Suspended through wire. Minimum 3 fixtures are needed to build a Curve Crown. Joint ceiling cup for up to 6 fittings can be ordered seperately.

Connection

2,3m textile cable with DCL plug or terminal block 3x4mm2. Ceiling cup included.

Classification

IP 20.

Design

Front Design 2022.

Standard colours

Other colours on request.

Product sheet

Designer



			Product specification
			The original Curve was designed for the renovation of Nationalmuseum and its library in 2018. There it took pride of place thanks to its attractive features taken from classical library lamps. This year, it has evolved to include a large pendant. Various models can be put together to create illumination of any size. Curve Crown may appear as a type of coronation over the interior, as well as a rhythmic circle dance with arms interlinked.


				POWER
				LUMINAIRE FLUX
				D/mm
				COLOUR
				ART.



					With incorporated LED module 230V






					10W
					710LM
					150
					White
					16041101-30


					10W
					774LM
					200
					White
					16041301-30


					10W
					783LM
					300
					White
					16041501-30


					10W
					710LM
					150
					Green
					16041112-30


					10W
					774LM
					200
					Green
					16041312-30


					10W
					783LM
					300
					Green
					16041512-30


					10W
					710LM
					150
					Pigeon blue
					16041108-30


					10W
					749LM
					200
					Pigeon blue
					16041308-30


					10W
					783LM
					300
					Pigeon blue
					16041508-30


					10W
					710LM
					150
					Ivory
					16041146-30


					10W
					749LM
					200
					Ivory
					16041346-30


					10W
					783LM
					300
					Ivory
					16041546-30


					With incorporated LED module DALI






					10W
					710LM
					150
					White
					16041101D30


					10W
					774LM
					200
					White
					16041301D30


					10W
					783LM
					300
					White
					16041501D30


					10W
					710LM
					150
					Green
					16041112D30


					10W
					774LM
					200
					Green
					16041312D30


					10W
					783LM
					300
					Green
					16041512D30


					10W
					710LM
					150
					Pigeon blue
					16041108D30


					10W
					774LM
					200
					Pigeon blue
					16041308D30


					10W
					783LM
					300
					Pigeon blue
					16041508D30


					10W
					710LM
					150
					Ivory
					16041146D30


					10W
					774LM
					200
					Ivory
					16041346D30


					10W
					783LM
					300
					Ivory
					16041546D30




Product specification The original Curve was designed for the renovation of Nationalmuseum and its library in 2018. There it took pride of place thanks to its attractive features taken from classical library lamps. This year, it has evolved to include a large pendant. Various models can be put together to create illumination of any size. Curve Crown may appear as a type of coronation over the interior, as well as a rhythmic circle dance with arms interlinked.
POWER	LUMINAIRE FLUX	D/mm	COLOUR	ART.
With incorporated LED module 230V
10W	710LM	150	White	16041101-30
10W	774LM	200	White	16041301-30
10W	783LM	300	White	16041501-30
10W	710LM	150	Green	16041112-30
10W	774LM	200	Green	16041312-30
10W	783LM	300	Green	16041512-30
10W	710LM	150	Pigeon blue	16041108-30
10W	749LM	200	Pigeon blue	16041308-30
10W	783LM	300	Pigeon blue	16041508-30
10W	710LM	150	Ivory	16041146-30
10W	749LM	200	Ivory	16041346-30
10W	783LM	300	Ivory	16041546-30
With incorporated LED module DALI
10W	710LM	150	White	16041101D30
10W	774LM	200	White	16041301D30
10W	783LM	300	White	16041501D30
10W	710LM	150	Green	16041112D30
10W	774LM	200	Green	16041312D30
10W	783LM	300	Green	16041512D30
10W	710LM	150	Pigeon blue	16041108D30
10W	774LM	200	Pigeon blue	16041308D30
10W	783LM	300	Pigeon blue	16041508D30
10W	710LM	150	Ivory	16041146D30
10W	774LM	200	Ivory	16041346D30
10W	783LM	300	Ivory	16041546D30
