Daikanyama

Finish

Shade in painted aluminum. Diffuser in opal glass.

LED info

System power 13W. Luminaire Luminous Flux 979LM. CCT 3000K.
SDCM 3. CRI >80. L80, 80.000h. 8259 - Excluding light source (see product specification).
8267 - Including dimable LED E27 light source (se product specification).

Installation

Suspended through wire.

Connection

2,3 m textile cable with DCL-plug (on/off) or terminal block (DALI) in ceiling cup. Terminal block 5x4mm2.

Classification

IP 20.

Design

Thomas Bernstrand 2013.

Standard colours

Other colours on request.



Product specification
E27 socket excluding light source
E27/Max 10W - - White 8259-1-01
E27/Max 10W - - Black 8259-1-06
E27/Max 10W - - Red 8259-1-07
E27/Max 10W - - Yellow 8259-1-14
E27/Max 10W - - Orange 8259-1-41
E27 socket including dimmable LED light source
E27/LED/9W/528LM 2700 >80 White 8267-1-01
E27/LED/9W/528LM 2700 >80 Black 8267-1-06
E27/LED/9W/528LM 2700 >80 Red 8267-1-07
E27/LED/9W/528LM 2700 >80 Yellow 8267-1-14
E27/LED/9W/528LM 2700 >80 Orange 8267-1-41
With built in LED module and driver. Possible with Dali dim option
LED/13W/979LM 3000 >80 White 12052101-30
LED/13W/979LM 3000 >80 White 12052101D30
LED/13W/979LM 3000 >80 Black 12052106-30
LED/13W/979LM 3000 >80 Black 12052106D30
LED/13W/979LM 3000 >80 Yellow 12052114-30
LED/13W/979LM 3000 >80 Yellow 12052114D30
LED/13W/979LM 3000 >80 Orange 12052141-30
LED/13W/979LM 3000 >80 Orange 12052141D30
D = /Dimmable with DALI or SwitchDim
