Fog

Finish

Painted steel. Shade in partly sand blasted clear glass. Textile cable. Other cable colours on request.

LED info

Dimmable LED retrofit light source GU10. System Power 4W - 7,2W (max 10W). Luminaire Luminous Flux 395LM - 510LM (see product specification).
CCT 2700K, 3000K or 4000K. SDCM 3. CRI>90.

Installation

Suspended through cable.

Connection

2,3m textile cable with DCL connection or terminal block 3x2,25mm2 in ceiling cup.

Classification

IP 20.

Design

Front Design 2014.

Standard colours

Other colours on request.

Product sheet

Designer

project

CONFIGURATOR



			Product specification
			With no apparent light source, Fog looks like a flaming planet, a mystical hovering globe. The glass is blasted on the inside, graduated smoothly from completely covering the bottom to disappearing up near the metal socket, where the light source is well hidden. Fog creates a new effect with classical materials and proven technology. The light appears to shoot up from the bottom of the globe, emitting an ambient glow that rises like a magically fiery fog.


				POWER
				KELVIN
				CRI
				COLOUR
				D/MM
				ART.



					LED GU10 socket


					4W/395LM
					2700K
					>80
					White
					300
					8311-1-01


					4W/395LM
					2700K
					>80
					Black
					300
					8311-1-06


					4W/395LM
					2700K
					>80
					Copper
					300
					8311-1-78


					4W/395LM
					2700K
					>80
					White
					350
					8311-3-01


					4W/395LM
					2700K
					>80
					Black
					350
					8311-3-06


					4W/395LM
					2700K
					>80
					Copper
					350
					8311-3-78


					4W/395LM
					2700K
					>80
					White
					400
					8311-5-01


					4W/395LM
					2700K
					>80
					Black
					400
					8311-5-06


					4W/395LM
					2700K
					>80
					Copper
					400
					8311-5-78


					6,2W/510LM
					3000K
					>90
					White
					300
					8312-1-01


					6,2W/510LM
					3000K
					>90
					Black
					300
					8312-1-06


					6,2W/510LM
					3000K
					>90
					Copper
					300
					8312-1-78


					6,2W/510LM
					3000K
					>90
					White
					350
					8312-3-01


					6,2W/510LM
					3000K
					>90
					Black
					350
					8312-3-06


					6,2W/510LM
					3000K
					>90
					Copper
					350
					8312-3-78


					6,2W/510LM
					3000K
					>90
					White
					400
					8312-5-01


					6,2W/510LM
					3000K
					>90
					Black
					400
					8312-5-06


					6,2W/510LM
					3000K
					>90
					Copper
					400
					8312-5-78


					5,5W/450LM
					4000K
					>96
					White
					300
					8312-1-01-40


					5,5W/450LM
					4000K
					>96
					Black
					300
					8312-1-06-40


					5,5W/450LM
					4000K
					>96
					Copper
					300
					8312-1-78-40


					5,5W/450LM
					4000K
					>96
					White
					350
					8312-3-01-40


					5,5W/450LM
					4000K
					>96
					Black
					350
					8312-3-06-40


					5,5W/450LM
					4000K
					>96
					Copper
					350
					8312-3-78-40


					5,5W/450LM
					4000K
					>96
					White
					400
					8312-5-01-40


					5,5W/450LM
					4000K
					>96
					Black
					400
					8312-5-06-40


					5,5W/450LM
					4000K
					>96
					Copper
					400
					8312-5-78-40






Product specification With no apparent light source, Fog looks like a flaming planet, a mystical hovering globe. The glass is blasted on the inside, graduated smoothly from completely covering the bottom to disappearing up near the metal socket, where the light source is well hidden. Fog creates a new effect with classical materials and proven technology. The light appears to shoot up from the bottom of the globe, emitting an ambient glow that rises like a magically fiery fog.
POWER	KELVIN	CRI	COLOUR	D/MM	ART.
LED GU10 socket
4W/395LM	2700K	>80	White	300	8311-1-01
4W/395LM	2700K	>80	Black	300	8311-1-06
4W/395LM	2700K	>80	Copper	300	8311-1-78
4W/395LM	2700K	>80	White	350	8311-3-01
4W/395LM	2700K	>80	Black	350	8311-3-06
4W/395LM	2700K	>80	Copper	350	8311-3-78
4W/395LM	2700K	>80	White	400	8311-5-01
4W/395LM	2700K	>80	Black	400	8311-5-06
4W/395LM	2700K	>80	Copper	400	8311-5-78
6,2W/510LM	3000K	>90	White	300	8312-1-01
6,2W/510LM	3000K	>90	Black	300	8312-1-06
6,2W/510LM	3000K	>90	Copper	300	8312-1-78
6,2W/510LM	3000K	>90	White	350	8312-3-01
6,2W/510LM	3000K	>90	Black	350	8312-3-06
6,2W/510LM	3000K	>90	Copper	350	8312-3-78
6,2W/510LM	3000K	>90	White	400	8312-5-01
6,2W/510LM	3000K	>90	Black	400	8312-5-06
6,2W/510LM	3000K	>90	Copper	400	8312-5-78
5,5W/450LM	4000K	>96	White	300	8312-1-01-40
5,5W/450LM	4000K	>96	Black	300	8312-1-06-40
5,5W/450LM	4000K	>96	Copper	300	8312-1-78-40
5,5W/450LM	4000K	>96	White	350	8312-3-01-40
5,5W/450LM	4000K	>96	Black	350	8312-3-06-40
5,5W/450LM	4000K	>96	Copper	350	8312-3-78-40
5,5W/450LM	4000K	>96	White	400	8312-5-01-40
5,5W/450LM	4000K	>96	Black	400	8312-5-06-40
5,5W/450LM	4000K	>96	Copper	400	8312-5-78-40
