Hoop
Finish
Painted aluminum and metal. Inner shade in matt opal glass.
LED information
System power 18W. Luminaire Luminous Flux 1715LM .
CCT 3000K. SDCM 3. CRI >80.
Installation
Suspended through wire. 8423, 8425, 8427 - Including white painted ceiling box.
8424, 8426, 8428 - Including ceiling hook and ceiling cup.
Connection
8423, 8425, 8427 - Snap-in terminal block 5x4mm2.
8424, 8426, 8428 - Terminal block 3x2,5mm2.
Classification
IP 20.
Design
Front 2018 (Hoop small). Front 2023 (Hoop large & drop).
Standard colours
Other colours on request.
| W | COLOUR | ART. |
|---|---|---|
| LED 1715LM/18W | White | 8425-3-01 |
| LED 1715LM/18W | White | 8425-3-01HFF |
| LED 1715LM/18W | Black | 8425-3-06 |
| LED 1715LM/18W | Black | 8425-3-06HFF |
| LED 1715LM/18W | Blue | 8425-3-08 |
| LED 1715LM/18W | Blue | 8425-3-08HFF |
| LED 1715LM/18W | Orange | 8425-3-41 |
| LED 1715LM/18W | Orange | 8425-3-41HFF |
| E27/max 20W | White | 8426-3-01 |
| E27/max 20W | Black | 8426-3-06 |
| E27/max 20W | Blue | 8426-3-08 |
| E27/max 20W | Orange | 8426-3-41 |
| HFF = Dimmable DALI, DSI or SwitchDim |
| W | COLOUR | ART. |
|---|---|---|
| LED 1715LM/18W | White | 8423301-30 |
| LED 1715LM/18W | White | 8423301D30 |
| LED 1715LM/18W | Black | 8423306-30 |
| LED 1715LM/18W | Black | 8423306D30 |
| LED 1715LM/18W | Blue | 8423308-30 |
| LED 1715LM/18W | Blue | 8423308D30 |
| LED 1715LM/18W | Orange | 8423341-30 |
| LED 1715LM/18W | Orange | 8423341D30 |
| E27/max 20W | White | 8424301 |
| E27/max 20W | Black | 8424306 |
| E27/max 20W | Blue | 8424308 |
| E27/max 20W | Orange | 8424341 |
| D = Dimmable DALI, DSI or SwitchDim |
| W | COLOUR | ART. |
|---|---|---|
| LED 1715LM/18W | White | 8427301-30 |
| LED 1715LM/18W | White | 8427301D30 |
| LED 1715LM/18W | Black | 8427306-30 |
| LED 1715LM/18W | Black | 8427306D30 |
| LED 1715LM/18W | Blue | 8427308-30 |
| LED 1715LM/18W | Blue | 8427308D30 |
| LED 1715LM/18W | Orange | 8427341-30 |
| LED 1715LM/18W | Orange | 8427341D30 |
| E27/max 20W | White | 8428301 |
| E27/max 20W | Black | 8428306 |
| E27/max 20W | Blue | 8428308 |
| E27/max 20W | Orange | 8428341 |
| D = Dimmable DALI, DSI or SwitchDim |
