Karo

Finish

Galvanized or painted steel. Outer cover of transparent polycarbonate. Equipped with patented dynamic diffuser no. 9902727-8.

LED info

System power 11W. Luminaire Luminous Flux 416LM.
CCT 3000K. SDCM 3. CRI >80.

Installation

Fits standard foundations 108 mm or above ground with accessory 93225-1-xx.

Connection

Terminal block 5x10mm2.

Classification

IK 08, IP 44.

Design

Per Sundstedt.

Standard colours

Other colours on request.

Product sheet

Designer

project


				Product specification
				Bollard with dynamic reflector which refracts the light away from critical dazzle
glare angles with great precision. You have to be in the immediate vicinity
of the lampshade to see it fully illuminated. At a distance, the lampshade
only gives a gentle light and thus indicates its position.

					W
				FINISH
				KG
				ART.

					LED 416/11W
					Black
					21,6
					3227-1-06

					LED 416/11W
					Grey
					21,6
					3227-1-10

					LED 416/11W
					Galvanized
					21,6
					3227-1-83

					Accessories

					Installationplate for installation above ground.
					Black

					93225-1-06

					Installationplate for installation above ground.
					Grey

					93225-1-10

					Installationplate for installation above ground.
					Galvanized

					93225-1-83

Product specification Bollard with dynamic reflector which refracts the light away from critical dazzle glare angles with great precision. You have to be in the immediate vicinity of the lampshade to see it fully illuminated. At a distance, the lampshade only gives a gentle light and thus indicates its position.
W	FINISH	KG	ART.
LED 416/11W	Black	21,6	3227-1-06
LED 416/11W	Grey	21,6	3227-1-10
LED 416/11W	Galvanized	21,6	3227-1-83
Accessories
Installationplate for installation above ground.	Black		93225-1-06
Installationplate for installation above ground.	Grey		93225-1-10
Installationplate for installation above ground.	Galvanized		93225-1-83
