Lumo pendant

Finish

Painted die-cast aluminum in black RAL 9005, orange RAL 3022, grey RAL 7047, green RAL 6011, browngrey RAL 7006. Raw aluminum model is untreated = deffects and spots are visable and change over time.Diffuser in matt acrylic. Can be ordered with diffuser in microprisma.Other colours on request. Joint ceiling cup for up to 6 pendants can be ordered seperately.

Led info

System power: 10W. Luminaire Luminous Flux: 830LM. CCT 3000K. SDCM 3. CRI 90. L70/55000H.
Alternative including dimmable GU10 LED lightsource 4,9W or 6,2W.

Installation

Suspended from ceiling 2,5 m cable. Including cable-cup.

Connection

Terminalblock 3x4 mm2. When DALI 5x4mm2.

Design

Thomas Bernstrand 2022.


Product specification Lumo is a classical, cone-shaped pendant, cast from a single piece of aluminium. The six-millimetre thick shade ends elegantly with a nice full radius. The diffuser is imperceptibly mounted into the shade in a way that avoids glare. Lumo can be built together with various railing fixtures to form straight, round, triangular or quadrilateral formations, suspended cleverly with the fixture’s cables.
POWER DIFFUSER MODEL KELVIN CRI COLOUR ART.
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Black 12130106-30
10W/830LM Matt acrylic DALI 3000K >90 Black 12130106D30
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Grey 12130111-30
10W/830LM Matt acrylic DALI 3000K >90 Grey 12130111D30
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Green 12130112-30
10W/830LM Matt acrylic DALI 3000K >90 Green 12130112D30
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Orange 12130141-30
10W/830LM Matt acrylic DALI 3000K >90 Orange 12130141D30
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Browngrey 12130166-30
10W/830LM Matt acrylic DALI 3000K >90 Browngrey 12130166D30
10W/830LM Matt acrylic 230V dim, on/off 3000K >90 Raw aluminum 12130185-30
10W/830LM Matt acrylic DALI 3000K >90 Raw aluminum 12130185D30
Including dimmable GU10 light source
GU10/Max 7W Matt acrylic 2700K/3000K >90 Black 12131106
GU10/Max 7W Matt acrylic 2700K/3000K >90 Grey 12131111
GU10/Max 7W Matt acrylic 2700K/3000K >90 Green 12131112
GU10/Max 7W Matt acrylic 2700K/3000K >90 Orange 12131141
GU10/Max 7W Matt acrylic 2700K/3000K >90 Browngrey 12131166
GU10/Max 7W Matt acrylic 2700K/3000K >90 Raw aluminum 12131185
LIGHTSOURCE GU10
4,9W/GU10/355LM 2700K >90 L70073
6,2W/GU10/515LM 3000K >90 L70074
ACCESSORIES
Diffuser in microprisma,only possible in LED models 912130101
Joint ceiling cup, up to 6 fittings White 91223101
Joint ceiling cup, up to 6 fittings Black 91223106
LUMO RAILS
Rail straight for 2 fixtures Black 12135106
Rail straight for 2 fixtures Grey 12135111
Rail straight for 2 fixtures Green 12135112
Rail straight for 2 fixtures Orange 12135141
Rail straight for 2 fixtures Browngrey 12135166
Rail straight for 3 fixtures Black 12135306
Rail straight for 3 fixtures Grey 12135311
Rail straight for 3 fixtures Green 12135312
Rail straight for 3 fixtures Orange 12135341
Rail straight for 3 fixtures Browngrey 12135366
Rail circle for 3 fixtures Black 12136106
Rail circle for 3 fixtures Grey 12136111
Rail circle for 3 fixtures Green 12136112
Rail circle for 3 fixtures Orange 12136141
Rail circle for 3 fixtures Browngrey 12136166
Rail circle for 5 fixtures Black 12136306
Rail circle for 5 fixtures Grey 12136311
Rail circle for 5 fixtures Green 12136312
Rail circle for 5 fixtures Orange 12136341
Rail circle for 5 fixtures Browngrey 12136366
Rail triangle for 3 fixtures Black 12137106
Rail triangle for 3 fixtures Grey 12137111
Rail triangle for 3 fixtures Green 12137112
Rail triangle for 3 fixtures Orange 12137141
Rail triangle for 3 fixtures Browngrey 12137166
Rail square for 4 fixtures Black 12137306
Rail square for 4 fixtures Grey 12137311
Rail square for 4 fixtures Green 12137314
Rail square for 4 fixtures Orange 12137341
Rail square for 4 fixtures Browngrey 12137366
