Lyx
Finish
Painted aluminum and zinced metal. Outer shade in polycarbonat with intergrated glass prisms.
LED info
System power 19W. Luminaire Luminous Flux: 1990-2240LM. CCT 3000K (2700K, 3500K or 4000K on request). SDCM 3. CRI 80. L70 60.000h.
Installation
On pole top D60 mm. Other mounting versions as double or tripple can be produced on request.
We recomend to use a local supplier of the pole as standards may vary between different countries. The pole we are able to supply are according to Swedish standards for buried foundation.
Connection
Terminal block 5x10mm2.
Classification
IK 08, IP 65.
Design
Jan Forsmark 2024.
Standard colours
Other colours on request.
| POWER | LUMINAIRE FLUX | KELVIN | CRI | FINISH | ART. | |
|---|---|---|---|---|---|---|
| LED 19W | 2190LM | 3000 | >80 | Black | On/Off | 12330106-30 |
| LED 19W | 2190LM | 3000 | >80 | Black | DALI | 12330106D30 |
| LED 19W | 2190LM | 3000 | >80 | Black | Zhaga | 12330106Z30 |
| POWER | LUMINAIRE FLUX | KELVIN | CRI | FINISH | ART. | |
|---|---|---|---|---|---|---|
| LED 19W | 1990LM | 3000 | >80 | Black | On/Off | 12331106-30 |
| LED 19W | 1990LM | 3000 | >80 | Black | DALI | 12331106D30 |
| LED 19W | 1990LM | 3000 | >80 | Black | Zhaga | 12331106Z30 |
| POWER | LUMINAIRE FLUX | KELVIN | CRI | FINISH | ART. | |
|---|---|---|---|---|---|---|
| LED 19W | 2209LM | 3000 | >80 | Black | On/Off | 12332106-30 |
| LED 19W | 2209LM | 3000 | >80 | Black | DALI | 12332106D30 |
| LED 19W | 2209LM | 3000 | >80 | Black | Zhaga | 12332106Z30 |
| POWER | LUMINAIRE FLUX | KELVIN | CRI | FINISH | ART. | |
|---|---|---|---|---|---|---|
| LED 19W | 2240LM | 3000 | >80 | Black | On/Off | 12333106-30 |
| LED 19W | 2240LM | 3000 | >80 | Black | DALI | 12333106D30 |
| LED 19W | 2240LM | 3000 | >80 | Black | Zhaga | 12333106Z30 |
