PXL

Finish

Painted metal or hot-dip galvanized metal.
Hot-dip galvanized has a rough surface with visible scratches.

LED info

System power 10W. Luminaire Luminous Flux 522LM. CCT 3000K. SDCM 3. CRI>90. L80 B10 50.000H.

Installation

Surface mounted wall installation.

Connection

Snap-in terminal block 3x4mm2. Knockout for external mains
cable from above.

Classification

IK 10, IP 65.

Design

Fredrik Mattson.

Standard colours

Other colours on request.

Product sheet

Designer

project


				Product specification
				 Galvanized has a ruff finish with visible scratches and other marks. IK 10.

					W
				FINISH
				KG
				ART

					LED 522LM/10W
					White
					1,5
					7795-1-01

					LED 522LM/10W
					Galvanized
					1,5
					7795-1-83

Product specification Galvanized has a ruff finish with visible scratches and other marks. IK 10.
W	FINISH	KG	ART
LED 522LM/10W	White	1,5	7795-1-01
LED 522LM/10W	Galvanized	1,5	7795-1-83
