Curve Cluster metal shades

Finish

Painted metal green RAL 6017, white RAL 9010. Diffuser in matt acrlylic.
Textile cable. Other colours on request.

LED info

Metal shades - Incorporated LED module. On/off or DALI. System power: 10W/shade. Luminaire Luminous Flux: see specification. CCT 3000K. SDCM 3. CRI 90. L70/50000H..

Installation

In ceiling.

Connection

Terminal block in ceiling box.

Design

Front Design 2024.

Product sheet

Designer



			Product specifikation
			Curve Cluster with metal shades - 5 fittings (15 shades) Small


				POWER
				LUMINAIRE FLUX
				Shade D/mm
				COLOUR
				MODEL

				ART.



					15x10W LED
					15x710LM
					150
					White
					Small
					On/Off
					16054101-30


					15x10W LED
					15x710LM
					150
					White
					Small
					DALI
					16054101D30


					15x10W LED
					15x774LM
					200
					White
					Small
					On/Off
					16054301-30


					15x10W LED
					15x774LM
					200
					White
					Small
					DALI
					16054301D30


					15x10W LED
					15x783LM
					300
					White
					Small
					On/Off
					16054501-30


					15x10W LED
					15x783LM
					300
					White
					Small
					DALI
					16054501D30


					15x10W LED
					15x710LM
					150
					Green
					Small
					On/Off
					16054112-30


					15x10W LED
					15x710LM
					150
					Green
					Small
					DALI
					16054112D30


					15x10W LED
					15x774LM
					200
					Green
					Small
					On/Off
					16054312-30


					15x10W LED
					15x774LM
					200
					Green
					Small
					DALI
					16054312D30


					15x10W LED
					15x783LM
					300
					Green
					Small
					On/Off
					16054512-30


					15x10W LED
					15x783LM
					300
					Green
					Small
					DALI
					16054512D30





Product specifikation Curve Cluster with metal shades - 5 fittings (15 shades) Small
POWER	LUMINAIRE FLUX	Shade D/mm	COLOUR	MODEL		ART.
15x10W LED	15x710LM	150	White	Small	On/Off	16054101-30
15x10W LED	15x710LM	150	White	Small	DALI	16054101D30
15x10W LED	15x774LM	200	White	Small	On/Off	16054301-30
15x10W LED	15x774LM	200	White	Small	DALI	16054301D30
15x10W LED	15x783LM	300	White	Small	On/Off	16054501-30
15x10W LED	15x783LM	300	White	Small	DALI	16054501D30
15x10W LED	15x710LM	150	Green	Small	On/Off	16054112-30
15x10W LED	15x710LM	150	Green	Small	DALI	16054112D30
15x10W LED	15x774LM	200	Green	Small	On/Off	16054312-30
15x10W LED	15x774LM	200	Green	Small	DALI	16054312D30
15x10W LED	15x783LM	300	Green	Small	On/Off	16054512-30
15x10W LED	15x783LM	300	Green	Small	DALI	16054512D30



			Product specifikation
			Curve Cluster with metal shades - 5 fittings (15 shades) Large


				POWER
				LUMINAIRE FLUX
				Shade D/mm
				COLOUR
				MODEL

				ART.



					15x10W LED
					15x710LM
					150
					White
					Large
					On/Off
					16055101-30


					15x10W LED
					15x710LM
					150
					White
					Large
					DALI
					16055101D30


					15x10W LED
					15x774LM
					200
					White
					Large
					On/Off
					16055301-30


					15x10W LED
					15x774LM
					200
					White
					Large
					DALI
					16055301D30


					15x10W LED
					15x783LM
					300
					White
					Large
					On/Off
					16055501-30


					15x10W LED
					15x783LM
					300
					White
					Large
					DALI
					16055501D30


					15x10W LED
					15x710LM
					150
					Green
					Large
					On/Off
					16055112-30


					15x10W LED
					15x710LM
					150
					Green
					Large
					DALI
					16055112D30


					15x10W LED
					15x774LM
					200
					Green
					Large
					On/Off
					16055312-30


					15x10W LED
					15x774LM
					200
					Green
					Large
					DALI
					16055312D30


					15x10W LED
					15x783LM
					300
					Green
					Large
					On/Off
					16055512-30


					15x10W LED
					15x783LM
					300
					Green
					Large
					DALI
					16055512D30





Product specifikation Curve Cluster with metal shades - 5 fittings (15 shades) Large
POWER	LUMINAIRE FLUX	Shade D/mm	COLOUR	MODEL		ART.
15x10W LED	15x710LM	150	White	Large	On/Off	16055101-30
15x10W LED	15x710LM	150	White	Large	DALI	16055101D30
15x10W LED	15x774LM	200	White	Large	On/Off	16055301-30
15x10W LED	15x774LM	200	White	Large	DALI	16055301D30
15x10W LED	15x783LM	300	White	Large	On/Off	16055501-30
15x10W LED	15x783LM	300	White	Large	DALI	16055501D30
15x10W LED	15x710LM	150	Green	Large	On/Off	16055112-30
15x10W LED	15x710LM	150	Green	Large	DALI	16055112D30
15x10W LED	15x774LM	200	Green	Large	On/Off	16055312-30
15x10W LED	15x774LM	200	Green	Large	DALI	16055312D30
15x10W LED	15x783LM	300	Green	Large	On/Off	16055512-30
15x10W LED	15x783LM	300	Green	Large	DALI	16055512D30



			Product specifikation
			Curve Cluster with metal shades - 9 fittings (27 shades) Small


				POWER
				LUMINAIRE FLUX
				Shade D/mm
				COLOUR
				MODEL

				ART.



					27x10W LED
					27x710LM
					150
					White
					Small
					On/Off
					16056101-30


					27x10W LED
					27x710LM
					150
					White
					Small
					DALI
					16056101D30


					27x10W LED
					27x774LM
					200
					White
					Small
					On/Off
					16056301-30


					27x10W LED
					27x774LM
					200
					White
					Small
					DALI
					16056301D30


					27x10W LED
					27x783LM
					300
					White
					Small
					On/Off
					16056501-30


					27x10W LED
					27x783LM
					300
					White
					Small
					DALI
					16056501D30


					27x10W LED
					27x710LM
					150
					Green
					Small
					On/Off
					16056112-30


					27x10W LED
					27x710LM
					150
					Green
					Small
					DALI
					16056112D30


					27x10W LED
					27x774LM
					200
					Green
					Small
					On/Off
					16056312-30


					27x10W LED
					27x774LM
					200
					Green
					Small
					DALI
					16056312D30


					27x10W LED
					27x783LM
					300
					Green
					Small
					On/Off
					16056512-30


					27x10W LED
					27x783LM
					300
					Green
					Small
					DALI
					16056512D30





Product specifikation Curve Cluster with metal shades - 9 fittings (27 shades) Small
POWER	LUMINAIRE FLUX	Shade D/mm	COLOUR	MODEL		ART.
27x10W LED	27x710LM	150	White	Small	On/Off	16056101-30
27x10W LED	27x710LM	150	White	Small	DALI	16056101D30
27x10W LED	27x774LM	200	White	Small	On/Off	16056301-30
27x10W LED	27x774LM	200	White	Small	DALI	16056301D30
27x10W LED	27x783LM	300	White	Small	On/Off	16056501-30
27x10W LED	27x783LM	300	White	Small	DALI	16056501D30
27x10W LED	27x710LM	150	Green	Small	On/Off	16056112-30
27x10W LED	27x710LM	150	Green	Small	DALI	16056112D30
27x10W LED	27x774LM	200	Green	Small	On/Off	16056312-30
27x10W LED	27x774LM	200	Green	Small	DALI	16056312D30
27x10W LED	27x783LM	300	Green	Small	On/Off	16056512-30
27x10W LED	27x783LM	300	Green	Small	DALI	16056512D30



			Product specifikation
			Curve Cluster with metal shades - 9 fittings (27 shades) Large


				POWER
				LUMINAIRE FLUX
				Shade D/mm
				COLOUR
				MODEL

				ART.



					27x10W LED
					27x710LM
					150
					White
					Large
					On/Off
					16057101-30


					27x10W LED
					27x710LM
					150
					White
					Large
					DALI
					16057101D30


					27x10W LED
					27x774LM
					200
					White
					Large
					On/Off
					16057301-30


					27x10W LED
					27x774LM
					200
					White
					Large
					DALI
					16057301D30


					27x10W LED
					27x783LM
					300
					White
					Large
					On/Off
					16057501-30


					27x10W LED
					27x783LM
					300
					White
					Large
					DALI
					16057501D30


					27x10W LED
					27x710LM
					150
					Green
					Large
					On/Off
					16057112-30


					27x10W LED
					27x710LM
					150
					Green
					Large
					DALI
					16057112D30


					27x10W LED
					27x774LM
					200
					Green
					Large
					On/Off
					16057312-30


					27x10W LED
					27x774LM
					200
					Green
					Large
					DALI
					16057312D30


					27x10W LED
					27x783LM
					300
					Green
					Large
					On/Off
					16057512-30


					27x10W LED
					27x783LM
					300
					Green
					Large
					DALI
					16057512D30





Curve Cluster metal - New 2024
