Curve Cluster single
Finish
Metal shades - Painted metal green RAL 6017, white RAL 9010. Diffuser in matt acrlylic.
Glas globes - White opal glass. Painted metal white RAL 9010 or copper finish.
Textile cable. Other colours on request.
LED info
Metal shades - Incorporated LED module. On/off or DALI. System power: 10W/shade. Luminaire Luminous Flux: see specification. CCT 3000K. SDCM 3. CRI 90. L70/50000H.
Glass globes - With E27 sockel excl. lightsource or with LED module DALI dimmable.
Installation
In ceiling hook and 3 m wire.
Connection
DCL-plug or terminal block in ceiling cup.
Design
Front Design 2024.
| POWER | LUMINAIRE FLUX | D/mm | COLOUR | MODEL | ART. | |
|---|---|---|---|---|---|---|
| CURVE CLUSTER WITH GLASS GLOBES | ||||||
| 3xE27 max 10W | 200/796 | White | Small | 16044101 | ||
| 3x10W | Under development | 200/796 | White | Small | DALI | 16044101D30 |
| 3xE27 max 10W | 200/796 | Copper | Small | 16044178 | ||
| 3x10W | Under development | 200/796 | Copper | Small | DALI | 16044178D30 |
| 3xE27 max 10W | 250/846 | White | Small | 16044301 | ||
| 3x10W | Under development | 250/846 | White | Small | DALI | 16044301D30 |
| 3xE27 max 10W | 250/846 | Copper | Small | 16044378 | ||
| 3x10W | Under development | 250/846 | Copper | Small | DALI | 16044378D30 |
| 3xE27 max 10W | 200/1122 | White | Large | 16047101 | ||
| 3x10W | Under development | 200/1122 | White | Large | DALI | 16047101D30 |
| 3xE27 max 10W | 200/1122 | Copper | Large | 16047178 | ||
| 3x10W | Under development | 200/1122 | Copper | Large | DALI | 16047178D30 |
| 3xE27 max 10W | 250/1172 | White | Large | 16047301 | ||
| 3x10W | Under development | 250/1172 | White | Large | DALI | 16047301D30 |
| 3xE27 max 10W | 250/1172 | Copper | Large | 16047378 | ||
| 3x10W | Under development | 250/1172 | Copper | Large | DALI | 16047378D30 |
| POWER | LUMINAIRE FLUX | D/mm | COLOUR | MODEL | ART. | ||||
|---|---|---|---|---|---|---|---|---|---|
| Curve Cluster with metal shades Small | |||||||||
| 3x10W | 3x710LM | 150/746 | White | Small | On/Off | 16043101-30 | |||
| 3x10W | 3x710LM | 150/746 | White | Small | DALI | 16043101D30 | |||
| 3x10W | 3x774LM | 200/796 | White | Small | On/Off | 16043301-30 | |||
| 3x10W | 3x774LM | 200/796 | White | Small | DALI | 16043301D30 | |||
| 3x10W | 3x783LM | 300/896 | White | Small | On/Off | 16043501-30 | |||
| 3x10W | 3x783LM | 300/896 | White | Small | DALI | 16043501D30 | |||
| 3x10W | 3x710LM | 150/746 | Green | Small | On/Off | 16043112-30 | |||
| 3x10W | 3x710LM | 150/746 | Green | Small | DALI | 16043112D30 | |||
| 3x10W | 3x774LM | 200/796 | Green | Small | On/Off | 16043312-30 | |||
| 3x10W | 3x774LM | 200/796 | Green | Small | DALI | 16043312D30 | |||
| 3x10W | 3x783LM | 300/896 | Green | Small | On/Off | 16043512-30 | |||
| 3x10W | 3x783LM | 300/896 | Green | Small | DALI | 16043512D30 | |||
| Curve Cluster with metal shades Large | |||||||||
| 3x10W | 3x710LM | 150/1072 | White | Large | On/Off | 16046101-30 | |||
| 3x10W | 3x710LM | 150/1072 | White | Large | DALI | 16046101D30 | |||
| 3x10W | 3x774LM | 200/1122 | White | Large | On/Off | 16046301-30 | |||
| 3x10W | 3x774LM | 200/1122 | White | Large | DALI | 16046301D30 | |||
| 3x10W | 3x783LM | 300/1222 | White | Large | On/Off | 16046501-30 | |||
| 3x10W | 3x783LM | 300/1222 | White | Large | DALI | 16046501D30 | |||
| 3x10W | 3x710LM | 150/1072 | Green | Large | On/Off | 16046112-30 | |||
| 3x10W | 3x710LM | 150/1072 | Green | Large | DALI | 16046112D30 | |||
| 3x10W | 3x774LM | 200/1122 | Green | Large | On/Off | 16046312-30 | |||
| 3x10W | 3x774LM | 200/1122 | Green | Large | DALI | 16046312D30 | |||
| 3x10W | 3x783LM | 300/1222 | Green | Large | On/Off | 16046512-30 |
