City Pole

Finish

Outer shade in painted aluminum. Internal shade in white painted aluminum. Can be made without grid on request. Possible to produce with double arm fitting on request.

LED info

System power 23W, 28W. Luminaire Luminous Flux 2215LM, 2455LM.
CCT 3000K. SDCM 3. CRI >80. L80 80.000h.

Installation

On pole top D60 mm.

Connection

Cable and quick-plug included when pole mounted.

Classification

IK 10, IP 65.

Design

Thomas Bernstrand 2016.

Standard colours

Other colours on request.

Product sheet

Designer


				Product specification
				With its archetypal shape and generous diameter, around half a metre, City
has a wide range of applications: outdoor or indoor, enhancing retail
environments, industries and public transport. There is no risk of glare as
the LED sits high in the characterful, steep cone, which also hides the
cast cooling flange

					W
				LIGHT
				COLOUR
				ART.

					LED 2215LM/23W
					Symmetrical
					Black
					3395-3-06

					LED 2215LM/23W
					Symmetrical
					Black
					3395-3-06HFF

					LED 2215LM/23W
					Symmetrical
					Beige grey
					3395-3-66

					LED 2215LM/23W
					Symmetrical
					Beige grey
					3395-3-66HFF

					LED 2455LM/28W
					Asymmetrical
					Black
					3396-3-06

					LED 2455LM/28W
					Asymmetrical
					Black
					3396-3-06HFF

					LED 2455LM/28W
					Asymmetrical
					Beige grey
					3396-3-66

					LED 2455LM/28W
					Asymmetrical
					Beige grey
					3396-3-66HFF

					HFF = Dimmable DALI.

					Prepared for Zhaga

					LED 2215LM/23W
					Symmetrical
					Black
					3395306Z30

					LED 2215LM/23W
					Symmetrical
					Beige grey
					3395366Z30

					LED 2455LM/28W
					Asymmetrical
					Black
					3396306Z30

					LED 2455LM/28W
					Asymmetrical
					Beige grey
					3396366Z30

					Double version - Produced on request

					LED 2215LM/23W
					Symmetrical
					-
					Spec-DoubleS

					LED 2455LM/28W
					Asymmetrical

					Spec-DoubleA

Product specification With its archetypal shape and generous diameter, around half a metre, City has a wide range of applications: outdoor or indoor, enhancing retail environments, industries and public transport. There is no risk of glare as the LED sits high in the characterful, steep cone, which also hides the cast cooling flange
W	LIGHT	COLOUR	ART.
LED 2215LM/23W	Symmetrical	Black	3395-3-06
LED 2215LM/23W	Symmetrical	Black	3395-3-06HFF
LED 2215LM/23W	Symmetrical	Beige grey	3395-3-66
LED 2215LM/23W	Symmetrical	Beige grey	3395-3-66HFF
LED 2455LM/28W	Asymmetrical	Black	3396-3-06
LED 2455LM/28W	Asymmetrical	Black	3396-3-06HFF
LED 2455LM/28W	Asymmetrical	Beige grey	3396-3-66
LED 2455LM/28W	Asymmetrical	Beige grey	3396-3-66HFF
HFF = Dimmable DALI.
Prepared for Zhaga
LED 2215LM/23W	Symmetrical	Black	3395306Z30
LED 2215LM/23W	Symmetrical	Beige grey	3395366Z30
LED 2455LM/28W	Asymmetrical	Black	3396306Z30
LED 2455LM/28W	Asymmetrical	Beige grey	3396366Z30
Double version - Produced on request
LED 2215LM/23W	Symmetrical	-	Spec-DoubleS
LED 2455LM/28W	Asymmetrical		Spec-DoubleA
