Convex Circle

Finish

Rail and shades in painted or galvanized metal. Custom rail shapes such as straight lines, ovals, other diameters and square models can be produced on request (see examples of custom button).

LED info

Information below is per light source. Including dimmable LED retrofit light source GU10. System power 5W or 7W. Luminaire Luminous Flux 422LM - 685LM (see product specification). CCT 2700K or 3000K. SDCM 3. CRI 80 or 90.

Installation

Suspended through wire.

Connection

2,3m cable with DCL plug or terminal block 3x4mm2 in ceiling cup.

Classification

IP 20.

Design

Jens Fager 2019.

Standard base colours

Other colours on request.

Product sheet

Designer

Example of Custom

project




Product specification
			Another of Zero’s big, popular families, Convex, has new additions in the pendant chandeliers Convex Circle. One has a diameter of 800 mm, the other a large 1400 mm with five and nine LED-equipped light sources respectively. The room’s natural centrepiece! Convex Mini is now the smallest pendant fixture in the family. It looks great in groups: individually or together with members of the same family. Standard versions available in black, white and galvanised metal. Convex comes with a dimmable GU10 LED 5W or 7W.


				POWER
				LUMINAIRE FLUX
				KELVIN
				CRI
				Color
				Diameter/mm
				ART.



					5x5W
					5x422LM
					2700K
					90
					White
					800
					8409301-27


					5x5W
					5x422LM
					2700K
					90
					Black
					800
					8409306-27


					5x5W
					5x422LM
					2700K
					90
					Galv
					800
					8409383-27


					5x7W
					5x685LM
					3000K
					80
					White
					800
					8409301-30


					5x7W
					5x685LM
					3000K
					80
					Black
					800
					8409306-30


					5x7W
					5x685LM
					3000K
					80
					Galv
					800
					8409383-30


					9x5W
					9x422LM
					2700K
					90
					White
					1400
					8409501-27


					9x5W
					9x422LM
					2700K
					90
					Black
					1400
					8409506-27


					9x5W
					9x422LM
					2700K
					90
					Galv
					1400
					8409583-27


					9x7W
					9x685LM
					3000K
					80
					White
					1400
					8409501-30


					9x7W
					9x685LM
					3000K
					80
					Black
					1400
					8409506-30


					9x7W
					9x685LM
					3000K
					80
					Galv
					1400
					8409583-30




Product specification Another of Zero’s big, popular families, Convex, has new additions in the pendant chandeliers Convex Circle. One has a diameter of 800 mm, the other a large 1400 mm with five and nine LED-equipped light sources respectively. The room’s natural centrepiece! Convex Mini is now the smallest pendant fixture in the family. It looks great in groups: individually or together with members of the same family. Standard versions available in black, white and galvanised metal. Convex comes with a dimmable GU10 LED 5W or 7W.
POWER	LUMINAIRE FLUX	KELVIN	CRI	Color	Diameter/mm	ART.
5x5W	5x422LM	2700K	90	White	800	8409301-27
5x5W	5x422LM	2700K	90	Black	800	8409306-27
5x5W	5x422LM	2700K	90	Galv	800	8409383-27
5x7W	5x685LM	3000K	80	White	800	8409301-30
5x7W	5x685LM	3000K	80	Black	800	8409306-30
5x7W	5x685LM	3000K	80	Galv	800	8409383-30
9x5W	9x422LM	2700K	90	White	1400	8409501-27
9x5W	9x422LM	2700K	90	Black	1400	8409506-27
9x5W	9x422LM	2700K	90	Galv	1400	8409583-27
9x7W	9x685LM	3000K	80	White	1400	8409501-30
9x7W	9x685LM	3000K	80	Black	1400	8409506-30
9x7W	9x685LM	3000K	80	Galv	1400	8409583-30

3d dwg
