Ginza - Vertical

A spotlight mounted on a strip: simple and practical. Above a table or in front of a wall, Ginza is available both horizontal and vertical. In addition, the fixture can twist around its axis to direct light at the desired angle without altering the balance of the strip.

Finish

Painted aluminum. White RAL 9010, black NCS S9000-N or orange RAL 4320S. Other colours on request.
Black and orange have black tube and cable. White are in all white. Microprisma diffuser.
3 x spotlights on a 650 mm long beam. Other lenghts on request.

LED info

System power: 3 x 10W. Luminaire Luminous Flux: 3 x 620LM. CCT 3000K. SDCM 3. CRI >80.

Installation

In ceiling, wire pendants.

Connection

Terminal block in ceiling cup.

Design

Thomas Bernstrand 2018.


Product specification
W COLOUR ART
LED 1860LM/30W White 8431-1-01
LED 1860LM/30W White 8431-1-01HFF
LED 1860LM/30W Black 8431-1-06
LED 1860LM/30W Black 8431-1-06HFF
LED 1860LM/30W Orange 8431-1-41
LED 1860LM/30W Orange 8431-1-41HFF
HFF = Dimmable DALI, SwitchDim.
