Lens large
Finish
Structure painted aluminum. Diffuser in opal acrylic.
LED info
System power 14W. Luminaire Luminous Flux 973LM. CCT 3000K (4000K on request). SDCM 3. CRI>80.
Installation
Suspended through cable.
Connection
2,3 m cable with terminal block 3x2,25mm. Dimable with cable only.
Classification
IP 20.
Design
Jens Fager 2010.
Standard colours
Other colours on request.
| W | FINISH | D | ART |
|---|---|---|---|
| E27/max 42W | White | 450 | 8101-3-01 |
| E27/max 42W | Black | 450 | 8101-3-06 |
| LED 973LM/14W | White | 450 | 8102-3-01 |
| LED 973LM/14W | White | 450 | 8102-3-01HFF |
| LED 973LM/14W | Black | 450 | 8102-3-06 |
| LED 973LM/14W | Black | 450 | 8102-3-06HFF |
| HFF = Dimmable with DALI, DSI, SwitchDim. |
