City Globe
Finish
Painted aluminum and metal. Black RAL 9005. Other colors on request. Outer shade in greytoned polycarbonate. Inner shade in crackled glass or open opalglass. IK 10.
Led info
System power 23W. Luminaire Luminous Flux 1900LM. CCT 3000K. SDCM 3. CRI >80. L80, 80.000h. Installation On wire, 3-6 mm.
Connection
Terminal block 5x4mm2 inside housing. Double conduit entry.
Design
Thomas Bernstrand 2019.
| POWER | KELVIN | CRI | INTERNAL SHADE | ART. | |
|---|---|---|---|---|---|
| LED | |||||
| 23W/1900LM | 3000K | >80 | Grey | On/Off | 12061306-30 |
| 23W/1900LM | 3000K | >80 | Grey | Dali | 12061306D30 |
| 23W/1900LM | 3000K | >80 | Cognac | On/Off | 12062306-30 |
| 23W/1900LM | 3000K | >80 | Cognac | Dali | 12062306D30 |
| 23W/1900LM | 3000K | >80 | Red | On/Off | 12063306-30 |
| 23W/1900LM | 3000K | >80 | Red | Dali | 12063306D30 |
| D = Dimmable DALI or SwitchDim. | |||||
| Prepared for Zhaga | |||||
| 23W/1900LM | 3000K | >80 | Grey | Zhaga | 12061306Z30 |
| 23W/1900LM | 3000K | >80 | Cognac | Zhaga | 12062306Z30 |
| 23W/1900LM | 3000K | >80 | Red | Zhaga | 12063306Z30 |
