Convex Mini

Finish

Shades in painted or galvanized metal. Colour matching textile cables. Other cable colours on request.

LED info

Information below is per light source. Including dimmable LED retrofit light source GU10. System power 5W or 7W. Luminaire Luminous Flux 422LM - 685LM (see product specification). CCT 2700K or 3000K. SDCM 3. CRI>80 or 90.

Installation

Suspended through cable.

Connection

2,3m textile cable with DCL plug or terminal block 3x4mm2 in ceiling cup.

Classification

IP 20.

Design

Jens Fager 2019.

Standard colours

Other colours on request.

product sheet

Designer




Product specification
			Another of Zero’s big, popular families, Convex Mini is now the smallest pendant fixture in the family. It looks great in groups: individually or together with members of the same family. Standard versions available in black, white and galvanised metal. Convex comes with a dimmable GU10 LED 5W or 7W.


				POWER
				LUMINAIRE FLUX
				KELVIN
				CRI
				Color
				ART.



					5W
					422LM
					2700K
					90
					White
					8408101-27


					5W
					422LM
					2700K
					90
					Black
					8408106-27


					5W
					422LM
					2700K
					90
					Galvanized
					8408183-27


					7W
					685LM
					3000K
					80
					White
					8408101-30


					7W
					685LM
					3000K
					80
					Black
					8408106-30


					7W
					685LM
					3000K
					80
					Galvanized
					8408183-30




Product specification Another of Zero’s big, popular families, Convex Mini is now the smallest pendant fixture in the family. It looks great in groups: individually or together with members of the same family. Standard versions available in black, white and galvanised metal. Convex comes with a dimmable GU10 LED 5W or 7W.
POWER	LUMINAIRE FLUX	KELVIN	CRI	Color	ART.
5W	422LM	2700K	90	White	8408101-27
5W	422LM	2700K	90	Black	8408106-27
5W	422LM	2700K	90	Galvanized	8408183-27
7W	685LM	3000K	80	White	8408101-30
7W	685LM	3000K	80	Black	8408106-30
7W	685LM	3000K	80	Galvanized	8408183-30
